    5000 Psi Wellhead Cross Over Spool 4 1/16"-5K R39 X 3 1/8"-5K R35 Flange

    Ask Lasest Price
    Brand Name : JC Wellhead
    Model Number : Crossover spool
    Certification : API 6A
    Price : Negotiable
    Payment Terms : T/T, L/C, D/P
    Supply Ability : 300 sets / month
    Delivery Time : 30-45 days
    • Product Details
    • Company Profile

    5000 Psi Wellhead Cross Over Spool 4 1/16"-5K R39 X 3 1/8"-5K R35 Flange

    Wellhead Crossover Spool 4 1/16"-5K R39 Flange x 3 1/8"-5K R35 Flange


    Crossover Spool is a sort of wellhead adapter spool is applied for Well Head extension, B.O.P. spacing, and Choke, Kill, and Production Manifold applications. The spacer spool usually has the same nominal end connections. The crossover spool is made of integral alloy steel forging, the wellhead adapter spool is designed and manufactured in accordance with API 6A, and have end connectors in same size or different size, rated working pressure. The spacer spool / riser spool is pressure-containing piece of equipment. As the part of wellhead equipment, the adapter spools have no provision for suspension of tubular member and for sealing of tubular members. The spacer spool provide separation between two components.


    ITEM NO.ITEM DESCRIPTION
    1Crossover Spool, API 6B :4-1/16""5K, R-39, 1- 1/4”x205mm long Studs(Gr-B7) with Nuts(Gr-2H) x 3-1/8"" 5K, R-35, 1-1/8”x185mm long Studs(Gr-B7)
    With Nuts(Gr-2H),MATERIALS SHALL
    CONFIRMED TO MEET THE REQUIREMENTS
    OFNACE MR-01-75.
    2GASKET "O" RING 3 1/8" 5000# R-35 SS316.
    3GASKET "O" RING 4 1/16" 5000# R-39 SS316
    4Stud Bolts +2 Hex Nuts 1-3/8" x 450mm Lg A 320 Gr
    L7/A 194 Gr 4 ANSI B18.2.1/ANSI B 18.2.2.

    5000 Psi Wellhead Cross Over Spool 4 1/16"-5K R39 X 3 1/8"-5K R35 Flange



    About ZZ TOP Oil Tools


    Jingcheng Petroleum Machinery Manufacturing Co.,Ltd was established in 2008, specialized in design and manufacturing of the oilfield wellhead equipment. From 2008 till now, YCJC is a registered supplier for CNPC, GWDC, CCDC in China to provide all kinds of oilfield wellhead equipment.


    In 2012, YCJC under the brand JC WELLHEAD jointed with ZZ TOP Oil Tools to establish an office in Xi'an engaging in abroad marketing,

    through these years of efforts, our wellhead equipment is exported to worldwide and enjoyed good reputation from the customers.


    Advantage:


    * Excellent and stable quality of the products conformed with API and ISO standard

    * Strict quality control on raw material and machining, we can arrange the SGS or BV to witness the test

    * We supply various wellhead products to meet the customers' operation.

    * Timely delivery, professional service on export procedure,

    * Product guarantee and best after-sales service.


    Product scope

    Wellhead valvesGate Valves, Plug Valves, Choke Valves, Check Valves, Mud Valves and various wellhead valve parts etc.
    Wellhead ManifoldChoke and Kill Manifold, Drilling Floor Manifold, Fracturing manifold, Well Testing Manifold.
    Wellhead EquipmentWellhead Christmas Tree / XTree, Casing Head, Casing Hanger, Tubing Head,Tubing Hanger, Casing Spool, Tubing Spool, Drilling Spool etc.
    Wellhead AdapterSpacer Spool / Riser Spool ,Flange Adapter, Union Flange, Double Studded Adapter Flange, Welded Neck Flange, Blind Flange,Companion Flange, Instrument Flange,Wellhead Clamp & Hub etc.
    Wellhead Integral FittingsHammer Union, Elbow, Swivel Joint, Block Cross, Block Tee, Straight Pipe, Pipe Loops etc.
    Well Control EquipmentAnnular BOP, RAM BOP, Sucker Rod BOP, BOP Stack, Wireline BOP etc
    Surface Well Testing PackageSurface Test Tree (Flowhead), Surface Safety Valve(SSV), ESD System, Data Header, Choke Manifold, Oil Diverter manifolds, Gas Diverter Manifold
