    15000psi Drill Stem Testing Tools AISI 4130 Select Tester Valve

    Ask Lasest Price
    Brand Name : Techcore
    Model Number : 5" Select Test Valve
    Certification : ISO
    Price : Negotiable
    Payment Terms : T/T, L/C, D/P
    Supply Ability : 50 sets / year
    Delivery Time : 30-45 days
    • Product Details
    • Company Profile

    15000psi Drill Stem Testing Tools AISI 4130 Select Tester Valve

    Select Tester Valve For Oil Well Drill Stem Testing Service


    The select tester valve is a kind of downhole tester valve in the well testing service. The tester valve is used in cased holes and designed with a full opening, annulus pressure operated tool. The select tester valve has the capabilities of taking multiple downhole closures where pipe manipulation is restricted and a full opening string is desired. The select tester valve is composed of four basic sections; ball valve section, upper hydraulic section, nitrogen section and the metering section and has the same basic features of the 15K LPR-N Tester Valve plus below additional features that include:


    * The select tester valve has ability to lock the ball valve in the open position at any point during the test.

    * The select tester valve also has ability to reactivate the tool for normal operations.


    Specification of Select tester valve / Downhole tester valve


    NO.Specification5”
    1OD5”(127mm)
    2ID2.25”(57mm)
    3Length(mm)288.2”(7319.5mm)
    4Working pressure15000 PSI(105Mpa)
    5Maximum open pressure differential5000PSI(35Mpa)
    6Tensile strength(Yield)2020.5kN
    7Internal Pressure Strength151Mpa
    8External Pressure Strength141Mpa
    9Torque strength30.9kN.m
    10Service EnvironmentMud, crude oil, natural gas with H2S, Apply to NACE MR0175-2003
    11End connection3 7/8CAS. BXP, 3 1/2 IF BXP
    12Service temperature-20oF~400oF

    15000psi Drill Stem Testing Tools AISI 4130 Select Tester Valve15000psi Drill Stem Testing Tools AISI 4130 Select Tester Valve



    About ZZ TOP OIL TOOLS


    Xi’an ZZ Top Oil Tools Co.,Ltd as head office registered in Xi’an City in 2010, and in 2016, ZZ TOP OIL TOOLS enlarged the downhole oil tools factory under the Brand - TECHCORE OIL TOOLS, which engages in designing and manufacturing the downhole oil tools including DST tools, Coiled tubing tools etc.


    We provide the clients highly efficient & expertise service as well as more comprehensive products to meet the customers' requirements during the work, and insists on "Traceability, Serialization" for each tools and related parts


    DST string tools: hydraulic jar, vertical shock absorber, radial shock absorber, RD safety circulating valve, high pressure retrievable packer with bypass, CHAMP packer, IPO valve, sleeve type drain valve, rupture disk sampler, super safety valve with control panel, BOP safety valve for downhole operation and so on.

    RTTS Serires: Full bore retrievable packer, full bore retrievable circulating valve, full bore retrievable safety joint,


    Tester Valve: downhole tester valve, select tester valve, LPR- N Valve, Tubing String Tester Valve


    Circulating valve: OMNI valve, multi-cycle circulating valve, RD Circulating valve, RD safety Circulating Valve, Hydraulic Circulating Valve
